Manufactured in India, supplied in Sydney
Wooden slat acoustic panels in Sydney
We manufacture wooden slat acoustic panels at our own plant at Palwal in Haryana, India, and supply them into Sydney. Made at our own plant in India and shipped into Port Botany.
- Substrate
- MDF, FR MDF, HDF or HDHMR
- Patterns
- 13-3, 14-2, 28-4 and 59-5
- Panel sizes
- 2440 x 192 mm and 2440 x 128 mm
- Thickness
- 14, 16 and 18 mm
- Coverage
- 96 sq ft per unit
- Lead time
- Longer than felt
- Minimum order
- 500 sq ft, about 46 sq m
- EN 13501-1 Class B s1 d0 on FR substrate
- Made at our own plant, Palwal, Haryana, India
- One batch across the order, no blending between runs
This comes from our own plant, not a trading desk. We do not have an office in your city and we will not invent one. What we can give you is factory pricing, consistent material and a technical answer before you commit.
01 / The material
What you are buying, and what it fixes in Sydney
Timber slats on an acoustic backing. The slats are the finish and the rhythm, the backing does the absorbing. Used where the room has to look considered rather than treated.
Work reaching us from Sydney is mostly apartment developments, offices, venues, schools, clinics, studios.
Timber frame in detached housing, concrete in apartments. Apartment party walls and slabs are the source of most complaints, and impact noise needs a resilient layer.
- Slats on felt backing The standard. Absorption comes from the backing behind the gaps, so the slat gap ratio is an acoustic decision, not only a visual one.
- Slats on a cavity Backing plus an air gap behind moves absorption lower, which matters in music rooms.
- Feature wall only Slats where they are seen, plain felt elsewhere, to hold the budget where it shows.
- What it will not do A tight slat pattern looks denser but absorbs less, because the open area is what lets sound reach the backing. If the visual you want and the RT target you need pull apart, we will tell you which one the pattern is serving.
Full specification
Thickness, density, NRC by frequency, fire class, standard sizes and build-up detail for wooden slat panels are on the main product page. This page covers what that means for a project in Sydney.
02 / Specification
The published figures, unchanged by location
These figures are published and they do not move. The thing worth arguing about is not the number on the sheet, it is which grade and which build-up suits the room you are treating.
- MDFStandard. Dry interiors, general commercial
- FR MDFFire rated. Public buildings and anywhere the specification calls for a class
- HDHMRMoisture resistant. Humid climates and rooms that see damp
| Substrate | MDF, FR MDF, HDF or HDHMR |
|---|---|
| Patterns | 13-3, 14-2, 28-4 and 59-5 |
| Panel sizes | 2440 x 192 mm and 2440 x 128 mm |
| Thickness | 14, 16 and 18 mm |
| Coverage | 96 sq ft per unit |
| Fire class | EN 13501-1 Class B s1 d0 on FR substrate |
If a consultant has set the target, we will quote against their figures rather than ours, and stay out of the scope they own. More on working with acoustic consultants.
03 / In this market
What we see driving Sydney briefs
- Apartments at volume
The same separating detail repeated across large developments. When it underperforms it underperforms in every unit, and that becomes a defect conversation.
- Mixed construction
Concrete frames with lightweight internal walls. The frame blocks, the partitions often do not, and people assume the opposite.
- Venues under homes
Late trading beneath apartments built around them, so the separating floor decides the hours.
- A long sea leg
One of the longer routes we run. Ordering to a real schedule matters, so we quote the full window.
- Assembly and performance rooms
School halls, community centres and church buildings carry assembly, performance and sport in one hard volume.
Architects working in Sydney usually need the build-up before the product. We will draw the section and mark what does the work. See how we support architects.
04 / Climate
What the Sydney climate rules in and rules out
Sydney is hot summers, mild winters and a distinct wet season, and that narrows the sensible material list before acoustics is even discussed.
PET felt handles the wet months without absorbing moisture or feeding mould. Timber and wood wool want a ventilated cavity and a stable indoor RH.
The risk we design against here is wet-season humidity behind linings.
For a Sydney interior where the finish leads, we will say plainly what each option costs you acoustically. See how we work with interior designers.
05 / Route to site
Supply into Sydney, start to site
| Ships from | Palwal, Haryana, India |
|---|---|
| Arrives at | Port Botany, then a short road run to site |
| Dispatch | 4 to 7 working days |
| Freight | Sea via Port Botany |
| Packing | Braced crates, slats supported along their length. Timber moves, so crates are kept flat and dry. |
| Lead time | Longer than felt. Confirmed against the pattern and substrate at quote stage. |
Standard items dispatch in 4 to 7 working days. The sea leg from India is long, so plan the full door to door window into the programme. We give real dates, not optimistic ones.
Sea freight into Port Botany, then a short road run to site. Air freight for samples and urgent quantities.
The same 500 sq ft minimum applies on export.
| Any specification | 500 sq ft, about 46 sq m |
|---|
One unit covers 96 sq ft, so the minimum is a little over five units. Substrate, slat pattern, width and thickness can be mixed inside the same order.
06 / Straight talk
Four honest warnings before you buy
-
The wrong product for the problem
A tight slat pattern looks denser but absorbs less, because the open area is what lets sound reach the backing. If the visual you want and the RT target you need pull apart, we will tell you which one the pattern is serving.
-
Coverage bought instead of a target
Lining every surface is a purchase, not a result. We would rather calculate the area against a reverberation target and sell you less of it.
-
Local approvals that nobody actually holds
We hold no Sydney certification and we will not borrow one. The test data we publish is ours, and we will send the reports rather than describe them.
Sydney: questions we are actually asked
Are these wooden slat acoustic panels made in Sydney?
No, and we will not say otherwise. We manufacture at our own plant at Palwal in Haryana, India, and supply into Sydney as the manufacturer rather than through a dealer. Made at our own plant in India and shipped into Port Botany. You buy at factory prices with one consistent batch across the order.
What do you look at first on a Sydney enquiry?
The same separating detail repeated across large developments. When it underperforms it underperforms in every unit, and that becomes a defect conversation. Concrete frames with lightweight internal walls. The frame blocks, the partitions often do not, and people assume the opposite. Those two things move the build-up far more than the panel figure does.
Is this the right material for Sydney conditions?
Sydney is hot summers, mild winters and a distinct wet season. PET felt handles the wet months without absorbing moisture or feeding mould. Timber and wood wool want a ventilated cavity and a stable indoor RH. The failure we design against here is wet-season humidity behind linings.
What is the delivery time into Sydney?
ships from: Palwal, Haryana, India, arrives at: Port Botany, then a short road run to site, dispatch: 4 to 7 working days. Standard items dispatch in 4 to 7 working days. The sea leg from India is long, so plan the full door to door window into the programme. We give real dates, not optimistic ones.
When are wooden slat acoustic panels the wrong purchase?
A tight slat pattern looks denser but absorbs less, because the open area is what lets sound reach the backing. If the visual you want and the RT target you need pull apart, we will tell you which one the pattern is serving.
Is there a minimum order, and how does it arrive?
The same 500 sq ft minimum applies on export. Any specification, 500 sq ft, about 46 sq m. One unit covers 96 sq ft, so the minimum is a little over five units. Substrate, slat pattern, width and thickness can be mixed inside the same order. Braced crates, slats supported along their length. Timber moves, so crates are kept flat and dry.
Next step
Tell us the room, we will tell you the build-up
Send what you have. We will give you a layer by layer build-up, a bill of quantities and a date material lands, and we will flag anything in the brief that will not achieve what you want.
